ORB
The Senquip ORB is a rugged telemetry device engineered for extreme environments, where high IP ratings are crucial, and external antennas are prone to damage. Typically mounted on poles, walls, or machinery exteriors, the ORB ensures reliable performance in harsh conditions.
QUAD
The Senquip QUAD is built for harsh environments where external antennas improve connectivity. It’s ideal for electrical enclosures, operator cabins, and external machine mounts. Designed for rugged industrial use, it ensures reliable data monitoring and remote asset management.
| Feature | Description | ORB | QUAD |
|---|---|---|---|
| Cellular Connectivity | 4G/5G LTE CAT M1 or 2G/3G/4G LTE CAT 1 with a SIM card slot for user-provided SIM. | Internal antenna | External antenna |
| Wi-Fi | 802.11 b/g/n (2.4GHz) with support for WPA, WPA2, and WPA3 authentication modes. | Internal antenna | Internal antenna |
| GPS | Supports GPS, BeiDou, Galileo, and GLONASS for location and speed tracking. | Internal antenna | External antenna |
| Bluetooth | Bluetooth 4.2: Supports receiving and transmitting BLE advertising messages, as well as connecting and pairing with Bluetooth devices. | Internal antenna | Internal antenna |
| Serial | RS232 and RS485 with configurable RS485 termination resistor, supporting capture, Modbus, and scripted modes. | 1 RS232, 1 RS485 | 1 RS232, 1 RS485 |
| CAN | High-speed CAN FD with unrestricted protocol support. | 1 | 2 |
| Multipurpose IO | Supports analog, digital, frequency, and pulse inputs, along with output sink and source, including 4-20mA sink and source. | 5 | |
| Mulipurpose IO | 2 × Analog + Digital Inputs, 1 × Output + Analog Input, 2 × 4-20mA Current Sources. | Yes | |
| Accelerometer | Supports pitch, roll, angle, and vibration detection with wake-from-sleep functionality. | Yes | Yes |
| Magnetic Sensor | Configurable to wake the device, enter setup mode, trigger a script, or perform all actions. | Yes | Yes |
| Tamper | Built-in tamper detection. | Yes | Yes |
| Power Supply | Supports 10VDC to 75VDC input, solar power with an inbuilt regulator, and an internal 1800mAh LiPo backup battery. | Yes | Yes |
| AA Batteries | Supports 4 × 1.6V Energizer lithium batteries for low-power, low-update-rate applications. | Yes | No |
| Boost Supply | Continues powering external sensors during power loss using an internal supply boosted from the backup battery. | 12V fixed | 5-25V settable |
| Edge Processing | Allows writing and deploying JavaScript applications to process data, generate alerts, control devices, and more. | Yes | Yes |
| Configuration | Accessible via an embedded web server, the Senquip Connect app, or the Senquip Portal online. | Yes | Yes |
| Endpoints | Supports third-party UDP, MQTT, and HTTP endpoints with customizable data packet formats. | ||
| Security | AES-256 data encryption for both in transit and at rest, with endpoint communications secured using PKI certificates. | ||
| Environmental | Operating temperature: -20°C to 80°C, with IP67-rated water ingress protection. | Yes | Yes |
Deploy rugged Senquip ORB and QUAD units for remote monitoring and telemetry in the most demanding sectors — Marine, Oil & Gas, and Defence. Supports Modbus data logging, sensor integration, and remote access. Ideal for remote sites and unmanned assets.
Read more about this is some title
Track machine health, performance trends, and prevent failures with real-time condition monitoring and asset tracking. Senquip enables vibration sensor integration, temperature/humidity monitoring, and predictive analytics to reduce downtime.
Read more about this is some title
Connect and control multiple remote assets with one platform. Whether it’s fleet management, agriculture IoT, or environmental monitoring, Senquip’s flexible solutions adapt to any application. Talk to our team for a custom configuration.
