Battery Chargers

Smart Multi-Stage Charging | 12V / 24V Programmable Output | Reliable Standby Power

Marine · Industrial · Oil & Gas

Sentinel 300P Series Programmable Battery Charger

The Sentinel 300P Series is a high-performance programmable battery charger designed for reliable power management in industrial, marine and engine-start applications. Its advanced multistage charging, low-ripple DC output and flexible 12V/24V configuration ensure long battery life and consistent performance across demanding environments. Built for critical systems, the Sentinel 300P Series delivers stable, efficient and intelligent charging for modern equipment.

10A Max Output

12/24V Programmable

1% Low Ripple

Auto Charging

Key Features Section

High-Efficiency Switch-Mode Charging: Designed to minimize heat and energy loss, the switch-mode architecture delivers stable DC output even when AC input voltage fluctuates.
Advanced Multistage Charging: The charger automatically switches between bulk, absorption, float and AutoBoost modes to ensure faster recovery after discharge and maintain long-term battery health.
Low Ripple Output: Produces less than 1% ripple, protecting VRLA, AGM, Gel and wet-cell batteries from damage caused by unstable or noisy charging signals.
AutoBoost Cell Equalization: Automatically increases charge voltage for a set duration to balance battery cells. Helps restore lost capacity without the risk of overcharging.
Temperature-Compensated Charging: When used with a remote sensor, the charger adjusts output voltage based on the surrounding temperature, preventing under-charging in cold conditions or over-charging in high heat.
Flexible 12V/24V Operation: Supports both 12-volt and 24-volt systems, making the Sentinel 300P suitable for a wide range of industrial, marine and standby applications.
Configurable Through Links or Software: Users can set charge voltage, battery type and operational behavior using onboard DIP switches or PC configuration software.
Built-In Alarms & Relay Outputs: Includes relay outputs for AC failure, low battery voltage, high battery voltage and charge failure, enabling integration with control panels and safety systems.
RS485 Communication Standard: Provides a reliable data interface for remote monitoring or integration with supervisory systems.

Applications

Marine Engine Starting Systems: Ensures consistent charging for vessel starter batteries exposed to vibration, salt, humidity and long operational hours.
Oil & Gas Pump Engines: Offers dependable charging performance for pump engines and remote oilfield equipment where reliability and safety are critical.
Industrial Control Panels: Maintains backup battery power for automation systems, hydraulic controls, electrical panels and mission-critical machinery.
Standby & Emergency Generators: Keeps generator starter batteries fully charged so engines can crank immediately during a power outage.
Mobile & Heavy-Duty Equipment: Suitable for construction machinery, service vehicles, cranes and equipment that rely on 12V or 24V batteries.
Remote Monitoring Stations: Ideal for field installations requiring continuous charging for communication equipment, sensors and telemetry units.
Industrial Battery Racks & Backup Systems: Maintains optimal charge levels in battery banks used for emergency shutdown systems, compressors and safety equipment.

Technical Specifications

Engineered for precision. Built for the harshest environments on Earth.

Category	Details
Input Power	95–250 VAC, 47–63 Hz wide-range input for stable operation
DC Output	Programmable 12 V / 24 V systems with up to 10 A output and <2% regulation
Ripple Voltage	Less than 1% ripple, compatible with VRLA, AGM, Gel, and NiCd batteries
Charging Modes	Float, bulk, absorption, and AutoBoost multi-stage charging
Relay Outputs	3–4 volt-free relays (model dependent) for AC fail, charge fail, and voltage alarms (1A @ 30 VDC)
Digital Inputs	2 configurable inputs for remote control or fault monitoring
Communication	RS485 standard; optional CAN / J1939 support on selected models
Operating Temperature	–40°C to +60°C (LCD visibility optimized from 0°C to +50°C)
Certifications	UL1236, CSA 22.2 compliant with NFPA 110 fault output support
Mounting Options	Open-frame or enclosed stainless-steel housing for panel or wall mounting
Protection	Self-resetting electronic output fuse with input fuse protection

How the Sentinel 300P Series Works

The Sentinel 300P Series uses a high-efficiency switch-mode power design to convert AC input into a clean, stable DC charging output. Once connected to the battery bank, the charger automatically evaluates the battery condition and selects the appropriate charging stage — bulk, absorption, float or AutoBoost.

During normal operation, the charger supplies a constant voltage and regulated current to maintain the battery in optimal condition. If the battery level drops or becomes unbalanced, the AutoBoost function temporarily increases voltage to equalize the cells without causing over-charging.

With the optional temperature sensor, the charger continuously adjusts voltage based on ambient conditions. This ensures accurate charging in both cold and hot environments. Built-in relays and alarms provide real-time feedback for AC failure, low battery voltage, high voltage and charge issues, making the Sentinel 300P suitable for mission-critical applications.

Technical FAQ

Common Questions Answered

Can't find your answer? Contact our engineers →

The charger supports a wide range of chemistries including VRLA, AGM, Gel, wet lead-acid and NiCd. Voltage settings can be programmed for both 12V and 24V systems.

Yes. The charger uses multistage charging and automatic voltage regulation to prevent overcharging and extend battery life. Temperature compensation further enhances protection.

All models include RS485 communication for integration with monitoring systems. Certain versions also support CAN / J1939 for advanced equipment networks.

Absolutely. Its rugged design, low ripple output and fault monitoring features make it ideal for marine engines, generator sets, industrial control panels and oil & gas equipment.

The charger includes input/output fusing, temperature-based voltage adjustment, low ripple charging and NFPA 110 compliant relay alarms for system safety.
